High spec wastegates for peak efficiency and performance

At DSPS, we live by the mantra "Quality Driven Performance." Our commitment to excellence and meticulous attention to detail yields unparalleled performance. As a premier wastegate design and manufacturing company, we specialise in delivering high-performance solutions tailored for motorsport teams.

Our track record speaks volumes, with our products securing victories in countless races and championships across diverse categories. Globally trusted by drivers, mechanics, and engineers, DSPS is synonymous with finely crafted components designed to deliver rapid and reliable results.

Enquire now
Image showing car parts

Turbocharging

Turbocharging is essential to enhance the power output and the efficiency of the engine, and hot exhaust gases require sophisticated control elements to support race strategies and improve your chances of success.

At DSPS we understand the constant high standards you need to achieve and maintain, and we will work closely with you from concept through to design and manufacture to help you reach peak performance.

Enquire now
Graphic showing a line drawing of a car part

What is a wastegate?

A wastegate, specifically an external wastegate, serves as a crucial component designed to manage boosts in high-performance engines. It regulates the flow of exhaust gases to the turbocharger's turbine, controlling the level of boost pressure generated.

To safeguard the engine, the wastegate prevents an unlimited increase in boost pressure. Both the turbocharger and engine benefit from this protective measure. Typically, the design is straightforward, functioning as a valve controlled by a pressure actuator linked to the turbo's boost pressure. A spring maintains the wastegate in a closed position. Once a predetermined boost level is reached, the compressed spring gradually opens the wastegate, allowing exhaust gases to bypass the turbine and regulate its speed.

Image showing race cars on a track

What are wastegates used for?

To sufficiently handle stock boost levels, an internal wastegate is usually a standard feature on most factory turbo systems. However, if you were fitting an aftermarket turbo or want more control of the boost, and as a result, the power output of your engine, then you will need to fit an external wastegate.

This type of wastegate is ideally for intended for high performance applications and as a result is more robustly built than internal variations.

What is the purpose of a wastegate?

A wastegate helps to regulate the flow of gases to the turbine and hence protects the turbocharger.

The wastegate activates once certain pressure values have been reached, ensuring any excess exhaust is redirected away from the turbo.

The main benefit of using an external wastegate is its ability to adapt to changing situations.

Image showing the inside of a car
Different types of wastegate
There are two main types of wastegate: internal and external, which we explain in more detail below.
Image showing a car part
Internal wastegate

Internal wastegates are usually fitted in most turbochargers, featuring a valve built into the housing of the turbine. An actuator, which features a sealed chamber and a spring, controls the valve and the chamber itself is linked to boost pressure (this is usually done via a pressure source located on the turbocharger’s compressor cover).

Image showing a car part
External wastegate

External wastegates are generally used in high power engines that are fitted to race and performance vehicles. They are self-contained mechanisms that are fitted to the exhaust header or manifold and typically feature larger inlets and outlets, along with larger actuator diaphragms and higher-pressure springs, which helps it to regulate increased boost pressures more efficiently.

Specific types of wastegate
To give you more precise detail on wastegate features, we’ve put together a short list of specific examples, so you have a better idea of how they are constructed.
WTCC Wastegate (GT3)
WTCC Wastegate (GT3)

The WTCC Wastegate is currently used in GT3, RallyX and a host of other cars. It delivers high performance in extreme conditions, offering drivers the sort of reliability they need on race day. It contains a Nimonic 80 forged valve, stainless steel billet machined valve guide housing, JIC boost connectors and an austenitic stainless-steel spring available in various rates.

Learn more
Springless Wastegate
Springless Wastegate

This is based on the highly successful DW1 wastegate and has a long history of helping rally and RallyX cars to repeatedly win races. The Springless Wastegate is designed to cope with extreme conditions and because the cap does not need to house a spring it is also a lot lower in height. Some of the features include Ti 6Al4V billet machined valve guide housing, JIC Boost connectors and 1 breather fitting and can also be supplied with a screened fitting.

Learn more
Super GT Wastegate (with sensor)
Super GT Wastegate (with sensor)

The Super GT Wastegate can be supplied with or without a sensor that can be used for signalor control. The design is derived from the DW1 wastegate and has also won the Japanese Super GT Championship. It is built to deal with extreme conditions and features #3 JIC Boost connectors, a Nimonic 80 forged valve and an austenitic stainless-steel spring available in a variety of rates.

Learn more
Graphic showing a line drawing of a car part

What is the best size wastegate to use?

The size of wastegate to use depends on a few different factors. Before you can determine the correct size, you need to account for things such as the size of the engine, its power output and maximum speed and the level of boost required. Once our engineers have all this relevant information, they can provide possible wastegate solutions that are suitable for the engine, ensuring the device can be safely installed for long-term use.

Image showing racing cars on a track

Championship-winning wastegates for all levels of motorsport

Our external wastegates are relied upon at the very highest level of motorsport, with teams performing in Indycar, WRX, WTCC, SGT and more relying on our specialist expertise to take them to the next level. We’re passionate about the technology we develop and are constantly looking for new ways to accelerate the success of the brands we work with.

DSPS are well respected on and off the track thanks to innovative valve technology that guarantees durability and performance. Our products boost performance reliably – our obsession with quality provides the performance you require.

Enquire now

FAQS

How often should a wastegate be inspected and serviced?

Regular inspection and maintenance are recommended. Factors like driving conditions and performance demands can influence the frequency of servicing.

Can a wastegate be upgraded for better performance?

Yes, wastegates can be upgraded to enhance performance. Upgrades may include improvements in materials, design, or overall functionality to achieve higher efficiency and responsiveness.

What signs indicate a malfunctioning wastegate?

Symptoms of a malfunctioning wastegate may include loss of power, unusual noises, or irregular boost pressure. If you experience any of these issues, it's advisable to have the wastegate inspected promptly.

Are wastegates compatible with all types of engines?

Wastegates are designed to be compatible with various turbo-charged engines, but it's essential to choose the right size and type based on the specific engine and performance requirements.

Can a wastegate be adjusted for different performance levels?

Yes, many wastegates are adjustable, allowing for fine-tuning of boost pressure levels. This adjustability is particularly useful for performance enthusiasts seeking optimal engine efficiency.

How does a wastegate contribute to fuel efficiency?

By regulating the boost pressure, a wastegate ensures that the engine operates within its optimal efficiency range. This can contribute to better fuel efficiency under varying driving conditions.

Are there different types of wastegates available?

Yes, there are various types of wastegates, including internal and external designs. The choice depends on factors such as engine configuration and performance goals.

Image showing a rev counter

Helping you achieve the best performance

Our mission is centred around helping you achieve the best performance on the motorsport stage. Through our cutting-edge products, we provide solutions that optimise your vehicle's capabilities. Our commitment to precision engineering, innovation, and reliability ensures that our products contribute significantly to enhancing the overall performance of your racing endeavours.
